FIX8::Message Class Reference

A complete Fix message with header, body and trailer. More...

#include <message.hpp>

Inheritance diagram for FIX8::Message:

Public Member Functions
template<typename InputIterator >
	Message (const F8MetaCntx &ctx, const f8String &msgType, const InputIterator begin, const size_t cnt, const FieldTrait_Hash_Array *ftha)
virtual	~Message ()
	Dtor. More...
MessageBase *	Header () const
MessageBase *	Trailer () const
MessageBase *	Header ()
MessageBase *	Trailer ()
unsigned	decode (const f8String &from, unsigned offset=0, unsigned ignore=0, bool permissive_mode=false)
F8API size_t	encode (f8String &to) const
F8API size_t	encode (char **to) const
	Encode message with minimal copying. More...
F8API Message *	clone () const
virtual bool	process (Router &rt) const
virtual bool	is_admin () const
virtual void	clear (bool reuse=true)
virtual void	set_custom_seqnum (unsigned seqnum)
unsigned	get_custom_seqnum () const
virtual void	set_no_increment (bool flag=true)
virtual bool	get_no_increment () const
bool	get_end_of_batch () const
void	set_end_of_batch (bool is_end_of_batch)
void	setup_reuse ()
void	push_unknown (Message *to) const
BaseField *	get_field_flattened (const unsigned short fnum) const
BaseField *	get_field_by_name_flattened (const char *tag) const
virtual F8API void	print (std::ostream &os, int depth=0) const
Public Member Functions inherited from FIX8::MessageBase
template<typename InputIterator >
	MessageBase (const struct F8MetaCntx &ctx, const f8String &msgType, const InputIterator begin, const size_t cnt, const FieldTrait_Hash_Array *ftha)
F8API	MessageBase (const MessageBase &from)
	Copy ctor. More...
F8API MessageBase &	operator= (const MessageBase &that)
	Assignment operator. More...
virtual	~MessageBase ()
	Dtor. More...
void	clear_positions ()
	empty the positions map More...
size_t	size () const
F8API unsigned	decode (const f8String &from, unsigned offset, unsigned ignore=0, bool permissive_mode=false)
unsigned	decode_group (GroupBase *grpbase, const unsigned short fnum, const f8String &from, unsigned s_offset, unsigned ignore)
F8API size_t	encode (std::ostream &to) const
F8API size_t	encode (char *to) const
F8API size_t	encode_group (const unsigned short fnum, std::ostream &to) const
F8API size_t	encode_group (const unsigned short fnum, char *to) const
virtual GroupBase *	create_nested_group (unsigned short fnum) const
F8API unsigned	check_positions ()
F8API unsigned	copy_legal (MessageBase *to, bool force=false) const
F8API unsigned	move_legal (MessageBase *to, bool force=false)
void	push_unknown (MessageBase *to) const
void	check_set_rlm (BaseField *where) const
const f8String &	get_msgtype () const
void	add_field_decoder (const unsigned short fnum, const unsigned pos, BaseField *what)
void	add_field (const unsigned short fnum, Presence::const_iterator itr, const unsigned pos, BaseField *what, bool check)
void	add_field (const unsigned short fnum, Fields::iterator fitr, const unsigned pos, BaseField *what, bool check=true)
void	add_field (const unsigned short fnum, const unsigned pos, BaseField *what, bool check=true)
void	set (const unsigned short field, FieldTrait::TraitTypes type=FieldTrait::present)
template<typename T >
bool	add_field (T *what)
bool	add_field (BaseField *what)
Groups &	get_groups ()
template<typename T >
bool	operator+= (T *what)
template<typename T >
MessageBase &	operator<< (T *what)
template<typename T >
bool	get (T &to) const
template<typename T >
bool	has () const
bool	is_legal (unsigned short fnum) const
template<typename T >
bool	is_legal () const
template<typename T >
const T *	get () const
template<typename T >
bool	operator() (T &to) const
template<typename T >
const T *	operator() () const
bool	have (const unsigned short fnum) const
Fields::const_iterator	find_field (const unsigned short fnum) const
BaseField *	get_field (const unsigned short fnum) const
BaseField *	get_field_by_name (const char *tag) const
Fields::const_iterator	fields_begin () const
Fields::const_iterator	fields_end () const
F8API BaseField *	replace (const unsigned short fnum, Presence::const_iterator itr, BaseField *with)
F8API BaseField *	replace (const unsigned short fnum, BaseField *with)
F8API GroupBase *	replace (const unsigned short fnum, GroupBase *with)
F8API BaseField *	remove (const unsigned short fnum, Presence::const_iterator itr)
F8API BaseField *	remove (const unsigned short fnum)
template<typename T >
GroupBase *	find_group () const
GroupBase *	find_group (const unsigned short fnum) const
template<typename T >
GroupBase *	find_add_group (GroupBase *grpbase=nullptr)
GroupBase *	find_add_group (const unsigned short fnum, GroupBase *grpbase=nullptr)
template<typename T >
void	append_group (T *what)
void	add_group (GroupBase *what)
MessageBase &	operator<< (GroupBase *what)
void	operator+= (GroupBase *what)
unsigned short	getPos (const unsigned short field) const
bool	add_trait (const FieldTrait &what)
template<typename InputIterator >
void	add_trait (const InputIterator begin, const size_t cnt)
virtual F8API void	print_field (const unsigned short fnum, std::ostream &os) const
virtual F8API void	print_group (const unsigned short fnum, std::ostream &os, int depth=0) const
const FieldTraits &	get_fp () const
void	print_fp (std::ostream &os)
virtual begin_string *	get_begin_string ()
virtual body_length *	get_body_length ()
virtual msg_type *	get_msg_type ()
virtual check_sum *	get_check_sum ()
const f8String &	get_unknown () const

Static Public Member Functions
static unsigned	calc_chksum (const char *from, const size_t sz, const unsigned offset=0, const int len=-1)
static unsigned	calc_chksum (const f8String &from, const unsigned offset=0, const int len=-1)
static f8String	fmt_chksum (const unsigned val)
static Message *	factory (const F8MetaCntx &ctx, const char *from, bool no_chksum=false, bool permissive_mode=false)
static F8API Message *	factory (const F8MetaCntx &ctx, const f8String &from, bool no_chksum=false, bool permissive_mode=false)
Static Public Member Functions inherited from FIX8::MessageBase
static unsigned	extract_element (const char *from, const unsigned sz, char *tag, char *val)
static unsigned	extract_element_fixed_width (const char *from, const unsigned sz, const unsigned val_sz, char *tag, char *val)
static unsigned	extract_element (const char *from, const unsigned sz, f8String &tag, f8String &val)
static void	set_tabsize (unsigned tabsize)
static unsigned	get_tabsize ()
static bool	has_group_count (const BaseField *bf)

Protected Attributes
MessageBase *	_header
MessageBase *	_trailer
unsigned	_custom_seqnum
bool	_no_increment
bool	_end_of_batch
Protected Attributes inherited from FIX8::MessageBase
Fields	_fields
FieldTraits	_fp
Positions	_pos
Groups	_groups
const f8String &	_msgType
const F8MetaCntx &	_ctx

Friends
std::ostream &	operator<< (std::ostream &os, const Message &what)

Additional Inherited Members
Static Protected Member Functions inherited from FIX8::MessageBase
static unsigned	extract_header (const f8String &from, char *len, char *mtype)
static unsigned	extract_trailer (const f8String &from, f8String &chksum)
Static Protected Attributes inherited from FIX8::MessageBase
static F8API unsigned	_tabsize = defaults::tabsize

Detailed Description

A complete Fix message with header, body and trailer.

Definition at line 1058 of file message.hpp.

Constructor & Destructor Documentation

template<typename InputIterator >

FIX8::Message::Message ( const F8MetaCntx &  ctx, const f8String &  msgType, const InputIterator  begin, const size_t  cnt, const FieldTrait_Hash_Array *  ftha  )

inline

Ctor.

Template Parameters

InputIterator

input iterator type

Parameters

ctx	- reference to generated metadata
msgType	- reference to Fix message type
begin	- InputIterator pointing to begining of field trait table
cnt	- number of elements in field trait table
ftha	field trait hash array

Definition at line 1087 of file message.hpp.

      : MessageBase(ctx, msgType, begin, cnt, ftha),_header(ctx._mk_hdr(true)),
        _trailer(ctx._mk_trl(true)), _custom_seqnum(), _no_increment(), _end_of_batch(true)
   {}

virtual FIX8::Message::~Message ( )

inlinevirtual

Dtor.

Definition at line 1094 of file message.hpp.

References _header, and _trailer.

{ delete _header; delete _trailer; }

Member Function Documentation

static unsigned FIX8::Message::calc_chksum ( const char *  from, const size_t  sz, const unsigned  offset = 0, const int  len = -1  )

inlinestatic

Generate a checksum from an encoded buffer, ULL version.

Parameters

from	char *buffer encoded Fix message
sz	size of msg
offset	starting offset
len	maximum length

Returns

calculated checknum

Definition at line 1170 of file message.hpp.

Referenced by calc_chksum().

   {
#if defined FIX8_SIZEOF_UNSIGNED_LONG && FIX8_SIZEOF_UNSIGNED_LONG == 8
      // steroid chksum algorithm by charles.cooper@lambda-tg.com
      // Basic strategy is to unroll the loop. normally adding in a loop
      // is slow because of the dependency, the cpu has to finish each loop
      // before it starts the next one and is unable to pipeline. one
      // way to get around this is to have multiple registers and have
      // multiple adds per loop, then consolidating at the end
      // as in unroll_checksum.
      // that is slow though because there is a lot of wasted space and
      // the cpu has to do a lot of adds.
      // key is that addition of a word is going to be faster
      // than addition of two chars, and also each word has 8 chars in it.
      // so we get 8 adds per loop. long1 + long2 is almost like
      // looping over two arrays of 8 chars and adding them element wise.
      // except for the overflow. so we have to keep track of the overflow
      // and get rid of it at the end.

      const unsigned long OVERFLOW_MASK (1UL << 8 | 1UL << 16 | 1UL << 24 | 1UL << 32 | 1UL << 40 | 1UL << 48 | 1UL << 56);
      unsigned long ret{}, overflow{};
      from += offset;
      const unsigned long elen (len != -1 ? len : sz);
      size_t ii{};
      for (; ii < (elen - elen % 8); ii += 8)
      {
         unsigned long expected_overflow((ret & OVERFLOW_MASK) ^ (OVERFLOW_MASK & *reinterpret_cast<const unsigned long*>(from + ii)));
         ret += *reinterpret_cast<const unsigned long*>(from + ii);
         overflow += (expected_overflow ^ ret) & OVERFLOW_MASK;
      }
      ret = COLLAPSE_INT64(ret);
      overflow = COLLAPSE_INT64(overflow);
      for (; ii < elen; ret += from[ii++]); // add up rest one by one
      return (ret - overflow) & 0xff;
#else
      // native chksum algorithm
      unsigned val(0);
      const char *eptr(from + (len != -1 ? len + offset : sz - offset));
      for (const char *ptr(from + offset); ptr < eptr; val += *ptr++);
      return val % 256;
#endif
   }

static unsigned FIX8::Message::calc_chksum ( const f8String &  from, const unsigned  offset = 0, const int  len = -1  )

inlinestatic

Generate a checksum from an encoded buffer, string version.

Parameters

from	source buffer encoded Fix message
offset	starting offset
len	maximum length

Returns

calculated checknum

Definition at line 1218 of file message.hpp.

References calc_chksum().

      { return calc_chksum(from.c_str(), from.size(), offset, len); }

virtual void FIX8::Message::clear ( bool  reuse = true )

inlinevirtual

Empty messages from container

Parameters

reuse

if true clear vector

Reimplemented from FIX8::MessageBase.

Definition at line 1155 of file message.hpp.

References FIX8::MessageBase::clear().

   {
      if (_header)
         _header->clear(reuse);
      if (_trailer)
         _trailer->clear(reuse);
      MessageBase::clear(reuse);
   }

Message * Message::clone

(

)

const

Clone this message. Performs a deep copy.

Returns

pointer to copy of this message

Definition at line 668 of file message.cpp.

References FIX8::BaseMsgEntry::_create, and FIX8::Minst::_do.

Referenced by FIX8::ConsoleMenu::RemoveMsg().

{
   const BaseMsgEntry& bme(_ctx._bme.find_ref(_msgType.c_str()));
   Message *msg(bme._create._do(true));
   // important not to pass force as true with copy_legal here
   copy_legal(msg);
   _header->copy_legal(msg->_header);
   _trailer->copy_legal(msg->_trailer);
   return msg;
}

unsigned FIX8::Message::decode ( const f8String &  from, unsigned  offset = 0, unsigned  ignore = 0, bool  permissive_mode = false  )

inline

Decode from string.

Parameters

from	source string
offset	in bytes to decode from
ignore	bytes to ignore counting back from end of message
permissive_mode	if true, ignore unknown fields

Returns

number of bytes consumed

Definition at line 1118 of file message.hpp.

References FIX8::MessageBase::decode().

   {
      const unsigned hlen(_header->decode(from, offset, 0, permissive_mode));
      const unsigned blen(MessageBase::decode(from, hlen, 0, permissive_mode));
#if defined FIX8_RAW_MSG_SUPPORT
      _begin_payload = hlen;
      _payload_len = blen;
      _rawmsg = from;
#endif
      return _trailer->decode(from, blen, ignore, permissive_mode);
   }

size_t Message::encode

(

f8String &

to

)

const

Encode message to stream.

Parameters

to	stream to encode to

Returns

number of bytes encoded

Definition at line 500 of file message.cpp.

References FIX8_MAX_MSG_LENGTH, and FIX8::HEADER_CALC_OFFSET().

{
   char output[FIX8_MAX_MSG_LENGTH + HEADER_CALC_OFFSET], *ptr(output);
   const size_t msgLen(encode(&ptr));
   to.assign(ptr, msgLen);
   return to.size();
}

size_t Message::encode

(

char **

to

)

const

Encode message with minimal copying.

Encode message to stream. Perform absolutely minimal copying of output buffer.

Parameters

to	pointer to pointer to buffer

Returns

number of bytes encoded; to ptr is updated with address of start of encoded message string

Definition at line 422 of file message.cpp.

References FIX8::IntervalTimer::AsDouble(), FIX8::IntervalTimer::Calculate(), FIX8::Common_BeginString(), FIX8::Common_BodyLength(), FIX8::Common_CheckSum(), FIX8::MessageBase::encode(), FIX8::HEADER_CALC_OFFSET(), and FIX8::FieldTrait::suppress.

{
   char *moffs(*hmsg_store + HEADER_CALC_OFFSET), *msg(moffs);

#if defined FIX8_CODECTIMING
   IntervalTimer itm;
#endif

   if (!_header)
      throw MissingMessageComponent("header");
   _header->get_msg_type()->set(_msgType);

#if defined FIX8_RAW_MSG_SUPPORT
   msg += (_begin_payload = _header->encode(msg)); // start
#if defined FIX8_PREENCODE_MSG_SUPPORT
   if (_preencode_len)
   {
      ::memcpy(msg, _preencode.data(), _payload_len =_preencode_len);
      msg += _preencode_len;
   }
   else
#endif
      msg += (_payload_len = MessageBase::encode(msg));
#else
   msg += _header->encode(msg); // start
#if defined FIX8_PREENCODE_MSG_SUPPORT
   if (_preencode_len)
   {
      ::memcpy(msg, _preencode.data(), _preencode_len);
      msg += _preencode_len;
   }
   else
#endif
      msg += MessageBase::encode(msg);
#endif

   if (!_trailer)
      throw MissingMessageComponent("trailer");
   msg += _trailer->encode(msg);
   const size_t msgLen(msg - moffs); // checksummable msglength
   const size_t hlen(_ctx._preamble_sz +
      (msgLen < 10 ? 1 : msgLen < 100 ? 2 : msgLen < 1000 ? 3 : msgLen < 10000 ? 4 :
       msgLen < 100000 ? 5 : msgLen < 1000000 ? 6 : 7));
   char *hmsg(moffs - hlen);
   *hmsg_store = hmsg;

   if (!_header->get_begin_string())
      throw MissingMandatoryField(Common_BeginString);
   _header->_fp.clear(Common_BeginString, FieldTrait::suppress);
   hmsg += _header->get_begin_string()->encode(hmsg);

   if (!_header->get_body_length())
      throw MissingMandatoryField(Common_BodyLength);
   _header->_fp.clear(Common_BodyLength, FieldTrait::suppress);

   _header->get_body_length()->set(static_cast<int>(msgLen));
   hmsg += _header->get_body_length()->encode(hmsg);

   if (!_trailer->get_check_sum())
      throw MissingMandatoryField(Common_CheckSum);
   _trailer->get_check_sum()->set(fmt_chksum(calc_chksum(moffs - hlen, msgLen + hlen)));
   _trailer->_fp.clear(Common_CheckSum, FieldTrait::suppress);
   msg += _trailer->get_check_sum()->encode(msg);

#if defined FIX8_CODECTIMING
   _encode_timings._cpu_used += itm.Calculate().AsDouble();
   ++_encode_timings._msg_count;
#endif

   *msg = 0;
   const size_t rlen(msg - *hmsg_store);
#if defined FIX8_RAW_MSG_SUPPORT
   _rawmsg.assign(*hmsg_store, rlen);
#endif
   return rlen;
}

static Message* FIX8::Message::factory ( const F8MetaCntx &  ctx, const char *  from, bool  no_chksum = false, bool  permissive_mode = false  )

inlinestatic

Using supplied metatdata context and raw input buffer, decode and create appropriate Fix message

Parameters

ctx	reference to metadata object
from	pointer to raw buffer containing one complete FIX message string only, no trailing or leading characters
no_chksum	if true, do not perform chksum verification
permissive_mode	if true, ignore unknown fields

Returns

pointer to newly created Message (which will be a super class of the generated type)

Definition at line 1238 of file message.hpp.

Referenced by FIX8::Session::process(), and FIX8::Session::retrans_callback().

   {
      const f8String to(from);
      return factory(ctx, to, no_chksum, permissive_mode);
   }

Message * Message::factory ( const F8MetaCntx &  ctx, const f8String &  from, bool  no_chksum = false, bool  permissive_mode = false  )

static

Using supplied metatdata context and raw input buffer, decode and create appropriate Fix message

Parameters

ctx	reference to metadata object
from	reference to string raw buffer containing one complete FIX message string only, no trailing or leading characters
no_chksum	if true, do not perform chksum verification
permissive_mode	if true, ignore unknown fields

Returns

pointer to newly created Message (which will be a super class of the generated type)

Definition at line 224 of file message.cpp.

References FIX8::F8MetaCntx::_bme, FIX8::IntervalTimer::AsDouble(), FIX8::IntervalTimer::Calculate(), FILE_LINE, FIX8::GeneratedTable< Key, Val >::find_ptr(), glout_debug, and FIX8::MAX_MSGTYPE_FIELD_LEN().

{
   char mtype[MAX_MSGTYPE_FIELD_LEN] {}, len[MAX_MSGTYPE_FIELD_LEN] {};
   const unsigned hlen(extract_header(from, len, mtype));

   if (!hlen)
   {
      glout_debug << "Message::factory throwing";
      throw InvalidMessage(from, FILE_LINE);
   }

   const unsigned mlen(fast_atoi<unsigned>(len));
   const BaseMsgEntry *bme(ctx._bme.find_ptr(mtype));
   if (!bme)
      throw InvalidMessage(mtype, FILE_LINE);
   Message *msg(bme->_create._do(false)); // shallow create
#if defined FIX8_CODECTIMING
   IntervalTimer itm;
#endif
   msg->decode(from, hlen, 7, permissive_mode); // skip already decoded mandatory 8, 9, 35 and 10
#if defined FIX8_CODECTIMING
   _decode_timings._cpu_used += itm.Calculate().AsDouble();
   ++_decode_timings._msg_count;
#endif

   msg->_header->get_body_length()->set(mlen);
   msg->_header->get_msg_type()->set(mtype);
#if defined FIX8_POPULATE_METADATA
   msg->check_set_rlm(fitr->second);
#endif

   const char *pp(from.data() + from.size() - 7);   // FIXME: assumes supplied string is one complete message only
   if (*pp != '1' || *(pp + 1) != '0') // 10=XXX^A
      throw InvalidMessage(from, FILE_LINE);
   if (!no_chksum) // permit chksum calculation to be skipped
   {
      const f8String chksum(pp + 3, 3);
      msg->_trailer->get_check_sum()->set(chksum);
      const unsigned chkval(fast_atoi<unsigned>(chksum.c_str())), mchkval(calc_chksum(from, 0, static_cast<unsigned>(from.size()) - 7));
      if (chkval != mchkval)
         throw BadCheckSum(mchkval);
   }

   return msg;
}

static f8String FIX8::Message::fmt_chksum ( const unsigned  val )

inlinestatic

Format a checksum into the required 3 digit, 0 padded string.

Parameters

val	checksum value

Returns

string containing formatted value

Definition at line 1224 of file message.hpp.

   {
      char buf[4] { '0', '0', '0', 0 };
      itoa<unsigned>(val, buf + (val > 99 ? 0 : val > 9 ? 1 : 2), 10);
      return f8String(buf);
   }

unsigned FIX8::Message::get_custom_seqnum ( ) const

inline

Get the custom sequence number.

Returns

seqnum the outbound sequence number to use for this message.

Definition at line 1259 of file message.hpp.

References _custom_seqnum.

Referenced by FIX8::Session::send_process().

{ return _custom_seqnum; }

bool FIX8::Message::get_end_of_batch ( ) const

inline

Get the end of batch flag

Returns

true or false

Definition at line 1271 of file message.hpp.

References _end_of_batch.

{ return _end_of_batch; }

BaseField* FIX8::Message::get_field_by_name_flattened ( const char *  tag ) const

inline

Search for field by longname in this message (either header, body or trailer).

Parameters

tag	field longname

Returns

pointer to field or 0 if not found

Definition at line 1315 of file message.hpp.

References FIX8::MessageBase::_ctx, get_field_flattened(), and FIX8::F8MetaCntx::reverse_find_fnum().

   {
      return get_field_flattened(_ctx.reverse_find_fnum(tag));
   }

BaseField* FIX8::Message::get_field_flattened ( const unsigned short  fnum ) const

inline

Search for field in this message (either header, body or trailer).

Parameters

fnum	field number

Returns

pointer to field or 0 if not found

Definition at line 1304 of file message.hpp.

References FIX8::MessageBase::_fields.

Referenced by get_field_by_name_flattened().

   {
      auto itr (_fields.find(fnum));
      return  itr != _fields.end() ? itr->second
            : (itr = _header->_fields.find(fnum)) != _header->_fields.end() ? itr->second
            : (itr = _trailer->_fields.find(fnum)) != _trailer->_fields.end() ? itr->second : nullptr;
   }

virtual bool FIX8::Message::get_no_increment ( ) const

inlinevirtual

Get the no increment flag.

Returns

value of _no_increment flag

Definition at line 1267 of file message.hpp.

References _no_increment.

{ return _no_increment; }

MessageBase* FIX8::Message::Header ( ) const

inline

Get a pointer to the message header.

Returns

pointer to header

Definition at line 1098 of file message.hpp.

References _header.

Referenced by FIX8::Session::compid_check(), FIX8::Session::handle_logon(), MyMenu::load_msgs(), FIX8::Session::send_process(), and FIX8::Session::sequence_check().

{ return _header; }

MessageBase* FIX8::Message::Header ( )

inline

Get a pointer to the message header, non const version.

Returns

pointer to header

Definition at line 1106 of file message.hpp.

References _header.

{ return _header; }

virtual bool FIX8::Message::is_admin ( ) const

inlinevirtual

Test whether this message is administrative.

Returns

true if administrative

Reimplemented in FIX8::TEX::Logon, FIX8::TEX::Logon, FIX8::TEX::Logout, FIX8::TEX::Logout, FIX8::TEX::SequenceReset, FIX8::TEX::SequenceReset, FIX8::TEX::Reject, FIX8::TEX::Reject, FIX8::TEX::ResendRequest, FIX8::TEX::ResendRequest, FIX8::TEX::TestRequest, FIX8::TEX::TestRequest, FIX8::TEX::Heartbeat, and FIX8::TEX::Heartbeat.

Definition at line 1151 of file message.hpp.

Referenced by MyMenu::load_msgs(), and FIX8::Session::process().

{ return false; }

void Message::print ( std::ostream &  os, int  depth = 0  ) const

virtual

Print the message to the specified stream.

Parameters

os	refererence to stream to print to
depth	not used

Reimplemented from FIX8::MessageBase.

Definition at line 680 of file message.cpp.

References FIX8::MessageBase::print().

{
   if (_header)
      os << *_header;
   else
      os << "Null Header" << endl;
   MessageBase::print(os);
   if (_trailer)
      os << *_trailer;
   else
      os << "Null Trailer" << endl;
}

virtual bool FIX8::Message::process ( Router &  rt ) const

inlinevirtual

Initiate callback to appropriate process method from metadata.

Parameters

rt	reference to router instance

Returns

true if correctly processed

Reimplemented in FIX8::TEX::DerivativeSecurityListRequest, FIX8::TEX::SecurityList, FIX8::TEX::SecurityListRequest, FIX8::TEX::SecurityTypes, FIX8::TEX::SecurityTypeRequest, FIX8::TEX::CrossOrderCancelRequest, FIX8::TEX::CrossOrderCancelReplaceRequest, FIX8::TEX::NewOrderCross, FIX8::TEX::OrderMassCancelReport, FIX8::TEX::OrderMassCancelRequest, FIX8::TEX::RegistrationInstructionsResponse, FIX8::TEX::RegistrationInstructions, FIX8::TEX::ListStrikePrice, FIX8::TEX::BidResponse, FIX8::TEX::BidRequest, FIX8::TEX::BusinessMessageReject, FIX8::TEX::MassQuote, FIX8::TEX::TradingSessionStatus, FIX8::TEX::TradingSessionStatusRequest, FIX8::TEX::SecurityStatus, FIX8::TEX::SecurityStatusRequest, FIX8::TEX::SecurityDefinition, FIX8::TEX::SecurityDefinitionRequest, FIX8::TEX::MassQuoteAcknowledgement, FIX8::TEX::QuoteStatusRequest, FIX8::TEX::QuoteCancel, FIX8::TEX::MarketDataRequestReject, FIX8::TEX::MarketDataIncrementalRefresh, FIX8::TEX::MarketDataSnapshotFullRefresh, FIX8::TEX::MarketDataRequest, FIX8::TEX::SettlementInstructions, FIX8::TEX::Quote, FIX8::TEX::QuoteRequest, FIX8::TEX::DontKnowTrade, FIX8::TEX::AllocationInstructionAck, FIX8::TEX::ListStatus, FIX8::TEX::ListStatusRequest, FIX8::TEX::ListExecute, FIX8::TEX::ListCancelRequest, FIX8::TEX::AllocationInstruction, FIX8::TEX::OrderStatusRequest, FIX8::TEX::OrderCancelReplaceRequest, FIX8::TEX::OrderCancelRequest, FIX8::TEX::NewOrderList, FIX8::TEX::NewOrderSingle, FIX8::TEX::PartyDetailsListReport, FIX8::TEX::PartyDetailsListRequest, FIX8::TEX::StreamAssignmentReportACK, FIX8::TEX::StreamAssignmentReport, FIX8::TEX::StreamAssignmentRequest, FIX8::TEX::UserNotification, FIX8::TEX::OrderMassActionRequest, FIX8::TEX::Email, FIX8::TEX::OrderMassActionReport, FIX8::TEX::ApplicationMessageReport, FIX8::TEX::ApplicationMessageRequestAck, FIX8::TEX::ApplicationMessageRequest, FIX8::TEX::MarketDefinitionUpdateReport, FIX8::TEX::MarketDefinition, FIX8::TEX::MarketDefinitionRequest, FIX8::TEX::TradingSessionListUpdateReport, FIX8::TEX::DerivativeSecurityListUpdateReport, FIX8::TEX::SettlementObligationReport, FIX8::TEX::SecurityDefinitionUpdateReport, FIX8::TEX::ContraryIntentionReport, FIX8::TEX::ExecutionAcknowledgement, FIX8::TEX::AllocationInstructionAlert, FIX8::TEX::AdjustedPositionReport, FIX8::TEX::SecurityListUpdateReport, FIX8::TEX::TradingSessionList, FIX8::TEX::TradingSessionListRequest, FIX8::TEX::ConfirmationRequest, FIX8::TEX::CollateralInquiryAck, FIX8::TEX::UserResponse, FIX8::TEX::UserRequest, FIX8::TEX::NetworkCounterpartySystemStatusResponse, FIX8::TEX::NetworkCounterpartySystemStatusRequest, FIX8::TEX::CollateralInquiry, FIX8::TEX::CollateralReport, FIX8::TEX::News, FIX8::TEX::CollateralResponse, FIX8::TEX::CollateralAssignment, FIX8::TEX::CollateralRequest, FIX8::TEX::AssignmentReport, FIX8::TEX::SettlementInstructionRequest, FIX8::TEX::ConfirmationAck, FIX8::TEX::AllocationReportAck, FIX8::TEX::AllocationReport, FIX8::TEX::TradeCaptureReportAck, FIX8::TEX::TradeCaptureReportRequestAck, FIX8::TEX::PositionReport, FIX8::TEX::RequestForPositionsAck, FIX8::TEX::RequestForPositions, FIX8::TEX::PositionMaintenanceReport, FIX8::TEX::PositionMaintenanceRequest, FIX8::TEX::Confirmation, FIX8::TEX::QuoteResponse, FIX8::TEX::QuoteStatusReport, FIX8::TEX::RFQRequest, FIX8::TEX::QuoteRequestReject, FIX8::TEX::OrderMassStatusRequest, FIX8::TEX::TradeCaptureReport, FIX8::TEX::TradeCaptureReportRequest, FIX8::TEX::MultilegOrderCancelReplace, FIX8::TEX::NewOrderMultileg, FIX8::TEX::DerivativeSecurityList, FIX8::TEX::Logon, FIX8::TEX::OrderCancelReject, FIX8::TEX::ExecutionReport, FIX8::TEX::Advertisement, FIX8::TEX::NewOrderSingle, FIX8::TEX::Logon, FIX8::TEX::IOI, FIX8::TEX::ExecutionReport, FIX8::TEX::Logout, FIX8::TEX::Logout, FIX8::TEX::SequenceReset, FIX8::TEX::SequenceReset, FIX8::TEX::Reject, FIX8::TEX::Reject, FIX8::TEX::ResendRequest, FIX8::TEX::ResendRequest, FIX8::TEX::TestRequest, FIX8::TEX::TestRequest, FIX8::TEX::Heartbeat, and FIX8::TEX::Heartbeat.

Definition at line 1147 of file message.hpp.

Referenced by myfix_session_client::handle_application(), hf_session_client::handle_application(), myfix_session_server::handle_application(), and hf_session_server::handle_application().

{ return (rt)(this); }

void FIX8::Message::push_unknown ( Message *  to ) const

inline

Copy _unknown string from this message to given message

Definition at line 1292 of file message.hpp.

References _header, _trailer, and FIX8::MessageBase::push_unknown().

   {
      if (_header)
         _header->push_unknown(to->_header);
      MessageBase::push_unknown(to);
      if (_trailer)
         _trailer->push_unknown(to->_trailer);
   }

virtual void FIX8::Message::set_custom_seqnum ( unsigned  seqnum )

inlinevirtual

Set the custom sequence number. Used to override and suppress automatic seqnum assignment.

Parameters

seqnum

the outbound sequence number to use for this message.

Definition at line 1255 of file message.hpp.

Referenced by FIX8::Session::send().

{ _custom_seqnum = seqnum; }

void FIX8::Message::set_end_of_batch ( bool  is_end_of_batch )

inline

Set the end of batch flag

Parameters

is_end_of_batch

true or false

Definition at line 1275 of file message.hpp.

Referenced by FIX8::FIXWriter::write_batch().

{ _end_of_batch = is_end_of_batch; }

virtual void FIX8::Message::set_no_increment ( bool  flag = true )

inlinevirtual

Set the no increment flag.

Parameters

flag	true means don't increment the seqnum after sending

Definition at line 1263 of file message.hpp.

Referenced by FIX8::Session::send().

{ _no_increment = flag; }

void FIX8::Message::setup_reuse ( )

inline

Setup this message to allow it to be resused This feature is experimental; do not use with pipelined mode

Definition at line 1279 of file message.hpp.

References FIX8::MessageBase::_fp, FIX8::Common_BeginString(), FIX8::Common_BodyLength(), FIX8::Common_CheckSum(), FIX8::Common_MsgSeqNum(), FIX8::MessageBase::remove(), FIX8::FieldTraits::set(), and FIX8::FieldTrait::suppress.

Referenced by MyMenu::load_msgs(), and MyMenu::new_order_single_recycled().

   {
      if (_header)
      {
         _header->_fp.set(Common_BeginString, FieldTrait::suppress);
         _header->_fp.set(Common_BodyLength, FieldTrait::suppress);
         delete _header->remove(Common_MsgSeqNum);
      }
      if (_trailer)
         _trailer->_fp.set(Common_CheckSum, FieldTrait::suppress);
   }

MessageBase* FIX8::Message::Trailer ( ) const

inline

Get a pointer to the message trailer.

Returns

pointer to trailer

Definition at line 1102 of file message.hpp.

References _trailer.

{ return _trailer; }

MessageBase* FIX8::Message::Trailer ( )

inline

Get a pointer to the message trailer, non const version.

Returns

pointer to trailer

Definition at line 1110 of file message.hpp.

References _trailer.

{ return _trailer; }

Friends And Related Function Documentation

std::ostream& operator<< ( std::ostream &  os, const Message &  what  )

friend

Inserter friend.

Parameters

os	stream to send to
what	message

Returns

stream

Definition at line 1364 of file message.hpp.

{ what.print(os); return os; }

Member Data Documentation

unsigned FIX8::Message::_custom_seqnum

protected

Definition at line 1066 of file message.hpp.

Referenced by get_custom_seqnum().

bool FIX8::Message::_end_of_batch

protected

Definition at line 1067 of file message.hpp.

Referenced by get_end_of_batch().

MessageBase* FIX8::Message::_header

protected

Definition at line 1065 of file message.hpp.

Referenced by Header(), push_unknown(), and ~Message().

bool FIX8::Message::_no_increment

protected

Definition at line 1067 of file message.hpp.

Referenced by get_no_increment().

MessageBase * FIX8::Message::_trailer

protected

Definition at line 1065 of file message.hpp.

Referenced by push_unknown(), Trailer(), and ~Message().

---

The documentation for this class was generated from the following files:

• message.hpp
• message.cpp
